Feature:
- 48kHz sampling frequency, 32-bit DPS processor (300M Clock Speed), 24-bit A/D and D/A conversion.
- 5 levels of automatic frequency shift mode selection for various scenes and microphone types.
- It adopts a 2-inch IPS true color display with a resolution of 320*240. Support Chinese/English menu display.
- 48 notch filter status LED indicators are displayed in real time, with 12 static + 12 dynamic notches per channel.
- It adopts one-key jog shuttle to quickly realize the mode, direct, lock, and Chinese and English selection functions.
- The frequency shifter is adjustable at ±10Hz (1Hz step), and the notch filter gain, Q value, and quantity are adjustable.
- Independent each channel gain, noise gate, compressor, frequency shift, notch, high and low pass, 7-band PEQ function settings.
- USB and RS-485 communication interface to connect PC upper computer and central control equipment.
- 5 files of preset modes can be edited freely through the PC host computer, and the mode archive and EQ archive import/export are supported.
Product Description
Feature:
- 48kHz sampling frequency, 32-bit DPS processor (300M Clock Speed), 24-bit A/D and D/A conversion.
- 5 levels of automatic frequency shift mode selection for various scenes and microphone types.
- It adopts a 2-inch IPS true color display with a resolution of 320*240. Support Chinese/English menu display.
- 48 notch filter status LED indicators are displayed in real time, with 12 static + 12 dynamic notches per channel.
- It adopts one-key jog shuttle to quickly realize the mode, direct, lock, and Chinese and English selection functions.
- The frequency shifter is adjustable at ±10Hz (1Hz step), and the notch filter gain, Q value, and quantity are adjustable.
- Independent each channel gain, noise gate, compressor, frequency shift, notch, high and low pass, 7-band PEQ function settings.
- USB and RS-485 communication interface to connect PC upper computer and central control equipment.
- 5 files of preset modes can be edited freely through the PC host computer, and the mode archive and EQ archive import/export are supported.
